BMP280 Sensor IC 30kPa To 110kPa Digital Pressure Sensors LGA8 Sensor Chip

BMP280 Sensor IC 30kPa To 110kPa Digital Pressure Sensors LGA8 Sensor Chip​

Product Description Of BMP280

BMP280 is an absolute barometric pressure sensor especially designed for mobile applications. The BMP280 sensor module is housed in an extremely compact package. Its small dimensions and the low power consumption allow the implementation in battery-powered devices.

Specification Of BMP280

Features Of BMP280

Pressure range: 300... 1100 hPa (equiv. to +9000... -500 m above/below sea level)
Package: 8-pin LGA metal-lid
Footprint : 2.0 x 2.5 mm2, height: 0.95 mm
Relative accuracy(700hP~900hPa @25℃): +0.12 hPa, equiv. to +1 m
Absolute accuracy(950hPa~10150hPa, 0..40 °C) typ. +1 hPa
Temperature coefficient offset(25°C~40°C @900hPa): 1.5 Pa/K, equiv. to 12.6 cm/K
Digital interfaces
- I2C (up to 3.4 MHz)
- SPI (3 and 4 wire, up to 10 MHz)
Current consumption: 2.7μA @ 1 Hz sampling rate
Temperature range: -40°C ~ +85 °C

Applications Of BMP280
Enhancement of GPS navigation (e.g. time-to-first-fix improvement, dead-reckoning, slope detection)
Indoor navigation (floor detection, elevator detection)
Outdoor navigation, leisure and sports applications
Weather forecast
Vertical velocity indication (e.g. rise/sink speed)
