AD8131ARMZ Integrated Circuit Chip Low Cost High Speed Differential Driver

AD8131ARMZ Integrated Circuit Chip Low Cost High Speed Differential Driver

Product Description Of AD8131ARMZ
AD8131ARMZis a differential or single-ended input to differential output driver requiring no external components for a fixed gain of 2. The AD8131ARMZ is a major advancement over op amps for driving signals over long lines or for driving differential input ADCs. The AD8131ARMZ has a unique internal feedback feature that provides output gain and phase matching that are balanced to –60dB at 10MHz, reducing radiated EMI and suppressing harmonics. Manufactured on ADI's next generation of XFCB bipolar process, the AD8131 has a –3 dB bandwidth of 400 MHz and delivers a differential signal with very low harmonic distortion.

Specifications Of AD8131ARMZ

Features Of AD8131ARMZ
High Speed:
400 MHz –3 dB Full Power Bandwidth
2000 V/µs Slew Rate
Fixed Gain of 2 with No External Components
Internal Common-Mode Feedback to Improve Gain and Phase Balance: –60 dB @10 MHz
Separate Input to Set the
Common-Mode Output Voltage
Low Distortion:
68 dB SFDR @ 5 MHz 200 Ω Load
Power Supply Range +2.7 V to ±5 V

Applications Of AD8131ARMZ
Video line driver
Digital line driver
Low power differential ADC driver
Differential in/out level shifting
Single-ended input to differential output driver

Other Supply Product Type

FAQ

Q: Are your products original?

A: Yes, all products are original, new original import is our purpose.

Q:Which Certificates do you have?

A:We are ISO 9001:2015 Certified Company and member of ERAI.

Q:Can you support small quantity order or sample?Is the sample free?

A:Yes,we support sample order and small order.Sample cost is different according to your order or project.

Q:How to ship my order? Is it safe?

A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.

Q:What about the lead time?

A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
