IRFP90N20DPBF Integrated Circuit Chip 200V Single N-Channel Power MOSFET Transistors
Product Description
IRFP90N20DPBF is a 200V, Single N-Channel Power MOSFET Transistor in a TO-247 package. This component supports various applications including DC motors, inverters, SMPS, lighting, load switches, and battery-powered applications. Available in both surface mount and through-hole packages with industry standard footprints for design flexibility.
Specifications
| Series |
HEXFET® |
| FET Type |
N-Channel |
| Technology |
MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) |
200 V |
| Current - Continuous Drain (Id) @ 25°C |
94A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) |
10V |
| Rds On (Max) @ Id, Vgs |
23mOhm @ 56A, 10V |
| Vgs(th) (Max) @ Id |
5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs |
270 nC @ 10 V |
| Vgs (Max) |
±30V |
| Input Capacitance (Ciss) (Max) @ Vds |
6040 pF @ 25 V |
| Power Dissipation (Max) |
580W (Tc) |
| Operating Temperature |
-55°C ~ 175°C (TJ) |
| Mounting Type |
Through Hole |
| Supplier Device Package |
TO-247AC |
| Package / Case |
TO-247-3 |
Key Features
- Planar cell structure for wide SOA
- Optimized for broadest availability
- Product qualification according to JEDEC
- Silicon optimized for applications
- Industry standard through-hole power
- High current rating
Applications
High frequency DC-DC converters
